STRATOS GIGA
In-line pump
Maximum performance at the highest levels of energy efficiency.
- High efficient EC motor (IE5).
- Single-stage, low pressure, in-line centrifugal pump.
- Easy to operate ‘Green Button’ technology and LED display.
- Control range is up to three times as high as conventional electronically-controlled pumps.
| Product description | Nominal flange diameter |
Port-to-port length L0 |
Rated power P₂ |
Gross weight, approx. m |
Article number |
GRD group |
Blind flange |
|---|---|---|---|---|---|---|---|
| Stratos GIGA (1.5") | 1.5" ANSI Class 125 [5] | 11.50 in | 2.30 – 6.40 hp | 107.34 – 108.03 lb | 2124480 – 2124484 | 11 | B |
| Stratos GIGA (2") | 2" ANSI Class 125 [7] | 12.00 in | 1.20 – 6.60 hp | 107.56 – 110.87 lb | 2124485 – 2124491 | 11 | - |
| Stratos GIGA (2.5") | 2.5" ANSI Class 125 [8] | 15.00 in | 0.80 – 7.10 hp | 118.36 – 139.97 lb | 2124492 – 2124499 | 11 | - |
| Stratos GIGA (3") | 3" ANSI Class 125 [4] | 18.00 in | 3.50 – 7.80 hp | 138.87 – 164.66 lb | 2124500 – 2124503 | 11 | - |
| Stratos GIGA (4") | 4" ANSI Class 125 [4] | 19.00 in | 3.50 – 9.10 hp | 184.50 – 199.94 lb | 2124504 – 2124507 | 11 | - |
