CRONOLINE-IL

In-line pump

  • Integral suction diffuser cast in volute inlet

  • All bolts “non-metric”.

  • Pump feet drilled and tapped.
  • Class 125 ANSI standard flanges.
Product description Nominal flange
diameter		 Number of
poles		 Port-to-port
length L₀		 Rated power
P₂
CronoLine-IL (1.25") 1.25" Class 125 ANSI 4 13.50 in 0.50 – 1.50 hp
CronoLine-IL (1.5") 1.5" Class 125 ANSI 2, 4 14.50 – 17.00 in 0.75 – 15.00 hp
CronoLine-IL (2") 2" Class 125 ANSI 2, 4 14.50 – 19.00 in 0.75 – 30.00 hp
CronoLine-IL (2.5") 2.5" Class 125 ANSI 2, 4 15.00 – 20.50 in 1.00 – 40.00 hp
CronoLine-IL (3") 3" Class 125 ANSI 2, 4 17.50 – 21.50 in 2.00 – 60.00 hp
CronoLine-IL (4") 4" Class 125 ANSI 2, 4 20.50 – 22.00 in 3.00 – 60.00 hp
