Integrated suction straightening vane.
Integrated suction straightening vane.
- Pump feet drilled and tapped.
- Suction and discharge pressure gauge tappings.
- Lifting eyes for easy installation.

| Product description | Nominal flange diameter |
Number of poles |
Port-to-port length L₀ |
Rated power P₂ |
|---|---|---|---|---|
| VeroLine-IPL (1.25") | 1.25" Class 125 ANSI | 4 | 10.98 in | 0.33 hp |
| VeroLine-IPL (1.5") | 1.5" Class 125 ANSI | 2, 4 | 10.00 – 12.99 in | 0.33 – 1.50 hp |
| VeroLine-IPL (2") | 2" Class 125 ANSI | 2, 4 | 11.50 – 14.02 in | 0.50 – 2.00 hp |
| VeroLine-IPL (2.5") | 2.5" Class 125 ANSI | 2, 4 | 13.50 in | 0.50 – 3.00 hp |
| VeroLine-IPL (3") | 3" Class 125 ANSI | 2, 4 | 14.02 – 15.00 in | 1.00 – 3.00 hp |
